unable to revolve selected item...help

[gogolwriter]

So I have solved the revolve be recreating the profile using the spline command - method - fix.

The problem as some of you have suggested is due to so many vertex points....due to my spline command having CV as a default. By using the "fix" approach to spline.

So the problem is due to my initial method of creation.

Self teaching myself autocad no doubt will lead to a number of wrong paths in order to find my way. Thanks for all your suggestions!

[ReMark]

You used the spline command. Why? You couldn't create the profile without using spline? Was this just an experiment?

[gogolwriter]

I was copying a pictures outline

[ReMark]

What is the object supposed to be?



Was the object larger initially then scaled down?



When you finished creating your 3D model what was the file size of your drawing?



I looked at your drawing. Units are set at decimal inches. The object measures roughly 0.85 x 5 yet it has 7505 objects. I can design a 3,000 gallon reactor with all nozzles and manways in 3D and come under that number. When I ran the OVERKILL command on it AutoCAD reported back there were 869 overlapping objects (which still leaves you with 6636 objects). I'd suggest you re-evaluate your methodology when doing something like this otherwise your 3D drawings will be unnecessarily huge as far as file size goes.

Edited December 16, 2013 by ReMark

[JD Mather]

I was copying a pictures outline



Use primitive geometry like arcs and lines.



Lines should never be created as splines.

More points (if a spline is needed) does not equate to a better curve, in fact, just the opposite is true.



Work close to the 0,0,0 origin.

Edited December 16, 2013 by JD Mather

[gogolwriter]

The initial jpeg photo I converted to a dwg and at first thought to copy the outline of the photo with arcs and lines, but found the outline to complex. So I gave the spline command a go...which made it easy to copy the outline...but then I ran into trouble because I used the cv method of spline. I then after input from the forum, that I needed to reduce the number of vertex....discovered that spline had another approach "fix" and so I use it and was able to revolve the profile.

Yes this was a experiment for the most part and spline was a new tool that none of the two autocad teaching books, that I went through never covered (one book covered basics with building a cabin as the main teaching example, and the other covering different approaches to 3d modeling)
