Wrong Extrusion

Recommended Posts

chubarka

Anyone here have a clue as to where this situation comes from?  I have made a single line

sketch with hopes of extruding it as a solid,  this is the result.

Chubarka


Wrong Extrusion.JPG

Share this post


Link to post
Share on other sites
cadasio

I would suggest you have thin feature ticked when you are doing your extrusion - this will occur automatically if you have a gap in your sketch.



If you fully define the sketch and/or use check sketch for feature and that may highlight any errors in it.

Share this post


Link to post
Share on other sites
Dadgad

I suggest drawing it with a continuous Polyline, following the commandline prompts carefully.

For the last segment use the CLOSE option.

Try using the PRESSPULL command and you should be good.

Follow and pay attention to the different commandline options.

Share this post


Link to post
Share on other sites
Cad64
1 hour ago, Dadgad said:

I suggest drawing it with a continuous Polyline, following the commandline prompts carefully.

For the last segment use the CLOSE option.

Try using the PRESSPULL command and you should be good.

Follow and pay attention to the different commandline options.



Dadgad, you're in the Solidworks section. ;)

Share this post


Link to post
Share on other sites
Dadgad
Posted (edited)

WHOOPS!  Never mind!  :oops:

Thanks for the headsup!  :beer:



@chubarka, your profile says Autocad 2007.  Should it?

Edited by Dadgad
Added user profile query.

Share this post


Link to post
Share on other sites
