f700es Posted April 15, 2008 Share Posted April 15, 2008 Thanks! you know... of all the things, I'm not sure how to increase the smoothness... can I do it in SketchUp easily or in KT? Can be done in SU either one of two ways, depending on how they were drawn. You can select the wheel and right-click and select "Smooth Soften Edges" or when you start to draw a circle in SU, after clicking on the circle icon, look at the bottom right corner. You will see "Sides" in the VCB (value control box). Default is 24 I think. Bump this up a bit, 48 or so. It will give circles a more rounded look. Quote Link to comment Share on other sites More sharing options...
CADken Posted April 18, 2008 Author Share Posted April 18, 2008 Alrighty, I've been asked by a nieghboring department to model one of their apparatus and here is my go at a color render: Here are some of the Clay renders: Quote Link to comment Share on other sites More sharing options...
CADken Posted April 18, 2008 Author Share Posted April 18, 2008 Wow, looks like a Engine to me: Quote Link to comment Share on other sites More sharing options...
Ritch7 Posted April 18, 2008 Share Posted April 18, 2008 oh my lord this is brillance, how long in all cadken have you been working on this? im curious Quote Link to comment Share on other sites More sharing options...
architecture68-raff Posted April 18, 2008 Share Posted April 18, 2008 Looks sharp. How many hours would you guess you've put into it so far? Just curious. Quote Link to comment Share on other sites More sharing options...
Ritch7 Posted April 18, 2008 Share Posted April 18, 2008 Looks sharp. How many hours would you guess you've put into it so far? Just curious. lol look at my previous post JYNX, Ps. your display avatar reminds me of the lead singer in Nickelback IM a rockstar baby Quote Link to comment Share on other sites More sharing options...
CADken Posted April 18, 2008 Author Share Posted April 18, 2008 oh my lord this is brillance, how long in all cadken have you been working on this? im curious Looks sharp. How many hours would you guess you've put into it so far? Just curious. Thanks for the kind words guys! well, I posted the request for people to send me pictures of their apparatus (on another forum) and I received PM's back along with pictures within about an hour or so of posting... I grabbed the very first one and started to create a model right away, here and there between actual work during the day... After one day of about 2 hours of work I had modeled the cab (including the windshield, doors, handles, door handles and trim)... the follow day I modeled the rear of the engine and all the compartments, handles, trim, etc. and it took about an hour... later that night I took approx. 2 hours to finalize just the rough mock up of the engine. I had 2 days break between due to a heavy work load and making sure I could create a bit of cushion to allow for more modeling time Today I spend 2 hours creating some of the smaller features, cab lights, tailights and cleaning up my design and adding colors... I'd say about 7 hours of work have been done to achieve this, 4 hours while at work adding little things here and there throughout the day and about 3 hours at home just messing around with ideas. Altho it's hard to judge since I'm doing a little here and there. Quote Link to comment Share on other sites More sharing options...
f700es Posted April 18, 2008 Share Posted April 18, 2008 Farkin' ROCKS man! Great job! David, I think we have a new image of the month on this one IMHO. Quote Link to comment Share on other sites More sharing options...
tzframpton Posted April 18, 2008 Share Posted April 18, 2008 dude, ken, that biotch looks friggin' awesome. I am jealous.... lol, good freakin work mang. Quote Link to comment Share on other sites More sharing options...
Ritch7 Posted April 18, 2008 Share Posted April 18, 2008 dude, ken, that biotch looks friggin' awesome. I am jealous.... lol, good freakin work mang. TOTATLY FARE OUT FREAKING AWESOME OUTRAGEOUS DUDE HIPY KOOL SHIZLE Quote Link to comment Share on other sites More sharing options...
lurchandpasta Posted April 18, 2008 Share Posted April 18, 2008 Don't you need a holiday in Italy, because I could sure do with some tutoring. Quote Link to comment Share on other sites More sharing options...
CADken Posted April 18, 2008 Author Share Posted April 18, 2008 Well, it's not as hard as it looks... if you've had experience with 3Ds Max the concepts are somewhat similar and just require a "designer's eye" I think, however that I have met my match: This 1949 Chevy Pickup is becoming the bane of my Modeling existance! All I can model is the rear... unfortunitely the cab and front end are going to require some extras skills I've been working on. Quote Link to comment Share on other sites More sharing options...
matt41129 Posted April 28, 2008 Share Posted April 28, 2008 Thats really cool, keep up the good work! Im a fellow firefighter myself. Quote Link to comment Share on other sites More sharing options...
CADken Posted April 28, 2008 Author Share Posted April 28, 2008 Well here is an updated render on the 7-6 Engine: Quote Link to comment Share on other sites More sharing options...
CADken Posted April 28, 2008 Author Share Posted April 28, 2008 Thats really cool, keep up the good work! Im a fellow firefighter myself. Thanks! always nice to have a few brother on board! We're having HAZMAT Operations refreshers at our station tonight, we're looking to reach our goal of having 90% of our active members State Certified FF 1. Quote Link to comment Share on other sites More sharing options...
matt41129 Posted April 30, 2008 Share Posted April 30, 2008 Yeah i have my Hazmat Operations and im almost a FF2. we have about the same tahts atleast a level 1 Quote Link to comment Share on other sites More sharing options...
CADken Posted May 1, 2008 Author Share Posted May 1, 2008 oh, by the way... in case anyone would like to see all the apparatus I model, visit my site: shoot me a PM sorry, no direct link due to the mass amount of spam that comes across! Newest Project: Quote Link to comment Share on other sites More sharing options...
Rob-GB Posted May 22, 2008 Share Posted May 22, 2008 CADken, not related to your obvious skills with cad designing,though pertinent to the designs in this thread, what is the reason for the oversized, step-like front fender on the appliance? I ask from interest as they are not part of the U.K fire appliances we usually see.( In the U.K) It is so refreshing to see an end user (so to speak) working on a new and improved design. So often merchandise or equipment is designed by people who have no "hands on" experience of the end use. Your posts have shown your enthusiasm for the excercise alongside your designing ability, best regards Rob. Quote Link to comment Share on other sites More sharing options...
97catintenn Posted May 23, 2008 Share Posted May 23, 2008 Well, it's not as hard as it looks... if you've had experience with 3Ds Max the concepts are somewhat similar and just require a "designer's eye" I think, however that I have met my match: This 1949 Chevy Pickup is becoming the bane of my Modeling existance! All I can model is the rear... unfortunitely the cab and front end are going to require some extras skills I've been working on. I just picked myself up off the floor. That is beautiful work! I can't believe sketchup can do this! And it's a free program... Quote Link to comment Share on other sites More sharing options...
CADken Posted May 23, 2008 Author Share Posted May 23, 2008 CADken, not related to your obvious skills with cad designing,though pertinent to the designs in this thread, what is the reason for the oversized, step-like front fender on the appliance? I ask from interest as they are not part of the U.K fire appliances we usually see.( In the U.K) It is so refreshing to see an end user (so to speak) working on a new and improved design. So often merchandise or equipment is designed by people who have no "hands on" experience of the end use. Your posts have shown your enthusiasm for the excercise alongside your designing ability, best regards Rob. Rob, the front "extended" fender on our apparatus contain extra equipment, some Engines have normal bumpers, and some have these custom bumpers that house extra hoses and tools for easy access. The company I volunteer for has 3 of the 4 apparatus with these extended bumpers to house extra hoses, hooks, nozzles, and other misc items. I just picked myself up off the floor. That is beautiful work! I can't believe sketchup can do this! And it's a free program... well, the actual red portion of the drawing and the background is the real thing, the orange colored portion is a render of the rear of the engine photoshopped onto the actual picture. Quote Link to comment Share on other sites More sharing options...
