dimension grip node stuck at arrow tip

Recommended Posts

rhgrafix

I searched the universe and can't find this answer,

Sometimes I find an existing dimension where one end has the node that has been collapsed to the tip of the arrow, I can't figure out how to pull it back off the arrow tip. I use 2011, any ideas?

Thanks!

R.L. Hamm

Share this post


Link to post
Share on other sites
SLW210

I moved your thread to the AutoCAD 2D Drafting, Object Properties & Interface Forum.



If I understand you correctly, just grab the grip on the dimension text and move it, you should now have an extension line.



If that doesn't work, the extension line may be turned off, check using properties.



If you still can't get it, post a .dwg that has this behavior.

Share this post


Link to post
Share on other sites
RobDraw
I searched the universe and can't find this answer



That must have taken a while. Welcome back.

Share this post


Link to post
Share on other sites
nestly

Following along with SLW's comments, does this illustrate the problem? .... a solution?



Dimension grips.gif

Share this post


Link to post
Share on other sites
SLW210

I also forgot to mention, you may also need to select "Keep Dimline with text" under Fit Options.
