Starkey

Insulation hatch

Recommended Posts

Starkey

Anyone have a hatch for the curvy lines usually associated with insulation?



Or send me to a tutorial where I can make my own if you so choose :wink:





-Taylor

Share this post


Link to post
Share on other sites
Dommy2Hotty

How about a linetype? AutoCAD has a linetype named BATTING.



I created a LISP routine to load the linetype and draw a line that has the correct scale based on the insulation size and drawing scale...I can give it to you, if you want...

Share this post


Link to post
Share on other sites
Starkey

Correct me if I'm wrong, but I can't run LISP routines in AutoCAD LT correct?



But I will search for that linetype...I didn't even think to check that. Thanks

Share this post


Link to post
Share on other sites
Dommy2Hotty
Correct me if I'm wrong, but I can't run LISP routines in AutoCAD LT correct?



But I will search for that linetype...I didn't even think to check that. Thanks



Oops...I didn't look before I posted...

Share this post


Link to post
Share on other sites
Starkey
Oops...I didn't look before I posted...



That's cool...I found the linetype, and scaling the line down wasn't a problem at all. Another problem solved on the cadtutor forums! :shock:

Share this post


Link to post
Share on other sites
Austriker

i have the same problem but didnt get mine to work so easy, some help please!!!

Share this post


Link to post
Share on other sites
Cad64

Can you at least give us a little information about what the problem is? Is it a problem with a hatch pattern or a problem with a lisp routine or a problem with a linetype or a problem with scaling? :?


Share this post


Link to post
Share on other sites
Starkey

Second the more information part....are you using Civil 3D 06 and having this problem?

Share this post


Link to post
Share on other sites
alec

hi,

I use Batting a lot for my insulation sections - I just opened that attachment and all I got was a page full numbers - lots of numbers.

Is there something else I shopuld do to it or have I got something set wrong?



cheers,



Smudger

Share this post


Link to post
Share on other sites
Noahma

Here is a lisp routine that I got from a friend years ago (still works great)



insul.lsp





should do the trick

Share this post


Link to post
Share on other sites
hugha

Here's a more efficient version of that BATTINSUL hatch. It looks the same, but all the unnecessary duplication and differing spacings have been removed.



*BATTINSUL,BATTINSUL (efficient small version)
;----------------------------------------------------------------------
; Pattern written by HatchKit v2.7 Hatch Pattern Editor
; HatchKit v2.7 Hatch Pattern Editor(c) Cadro Pty Ltd 1990-2007.
; [url="http://www.cadro.com.au/hatchkit/"]www.cadro.com.au/hatchkit/[/url]
;----------------------------------------------------------------------
;-Template=BATTINSUL,BATTINSUL
;-Source =C:\Documents and Settings\Hugh\My Documents\BATTINSUL.PAT
;-Date =25/09/2007
;-Time =9:02:49 PM
;----------------------------------------------------------------------
74.8352172299,0.1771,0.9579,12.8711770908,0.0268730411076,0.111,-13.9382297459
-67.1012536037,0.2036,0.7338,2.47190993325,0.0439687288314,0.2558,-8.33088282042
-14.064635312,0.08823,0.1448,4.8119408458,0.040597225286,0.08127,-9.2185165207
14.0646353119,0.1671,0.125,4.48784567492,0.0405972252861,0.08127,-9.21851652067
-74.8352172299,0.1281,1.065,1.17805265514,0.0268730411076,0.111,-13.9382297459
25.0089453241,0.206,1.065,2.59721654072,0.0353121802716,0.1414,-10.5502515941
52.4486755958,0.2459,0.1448,2.8099019349,0.052977168901,0.1374,-6.98917048922
-52.448675596,0.004471,0.2537,4.3166685543,0.052977168901,0.1374,-6.9891704892
83.8125227449,0.004471,0.2537,12.5016343296,0.011072157934,0.2459,-33.8527400974
67.1012536037,0.03078,0.4982,6.11477288716,0.0439687288314,0.2558,-8.33088282042
-25.0089453241,0,1.125,8.09443505337,0.0353121802716,0.14144,-10.5502115941
-83.8632671306,0.3033,0.4982,9.09534825883,0.030199681935,0.2459,-12.2557392326
83.2549943627,0.1305,0.7338,3.40577841418,0.0663597207299,0.2257,-5.46367789881
-83.2549943627,0.1771,0.9579,2.28359948464,0.0663597207299,0.2257,-5.46367789881





There's no reason for hatch patterns to contain that level of repetition.



Hugh Adamson

www.cadro.com.au

BATTINSUL.zip

Edited by SLW210
Code Tags!!

Share this post


Link to post
Share on other sites
bold architecture design
Here is a lisp routine that I got from a friend years ago (still works great)



[ATTACH]2703[/ATTACH]





should do the trick



Hi, pretty new to the Forum and with a Vectorworks background, but slowly (after 5 years!) picking up ACAD. This routine is great but each time I use the command 'Insul' it turns off my OSNAP settings and I have to turn them on again and they've all been turned off by default. Little bit frustrating as I need the OSNAP generally each time I use the Insul lsp routine. Any advice greatly appreciated. :?

Share this post


Link to post
Share on other sites
hugha

Open the insul.lsp wsith a text editor (even Notepad) and comment out this line



(setvar "OSMODE" 0)



with a semicolon prefix like this.



; (setvar "OSMODE" 0)



Save the file - you will then keep your osnaps as is.



I haven't tested how it will affect the routine's operation but it could be worth a try.

Share this post


Link to post
Share on other sites
hakelu

Hi guys.



I tried to use the hatch file you provided, but it wont draw curves, but non-continueous lines crossing each other, it is ugly.



I tried the lisp routine as well, but once finished setting parameters, it works for a few seconds, countinueously writing: "A" is unkown order", and so on... and then nothing happens.



I use AutoCAD 2007 hungarian version.



Any suggestions?



Thanks in advance.

Share this post


Link to post
Share on other sites
Audryb
Here is a lisp routine that I got from a friend years ago (still works great)



[ATTACH]2703[/ATTACH]





should do the trick



this is a great lisp routine, but I'm wondering if there's a way to edit it so that the angles of the insulation from one arc to the next are a little steeper? I'd like arcs of the finished batt to come closer together or even touch, but I'm not sure what variables to tweak.



thanks!

Share this post


Link to post
Share on other sites
Andrew1979

By the way, the site isn't finishes as yet so hoepfully no complaints. :D

Share this post


Link to post
Share on other sites
Cyberkid

Do anyone know how to get an LISP rutine that makes a zigzag insulation like this:



best regards to all



cyberkid


Share this post


Link to post
Share on other sites
Andrew1979

theres already a linetype in AutoCAD called zig zag
