If you are still trying to get those symbols, what I did when I was using LT and not mechanical, I had to use the text override to get them in the dimension. Here are the ones I remember:

{\Famgdt;v} for a counterbore

{\Famgdt;w} for countersink

{\Famgdt;x} for depth of hole


You also have unicode or the alt method like \U+00B0 or alt+248 for the ° symbol.

Link to comment
Share on other sites

So we're talking about: countersink, depth, bore, radius, spotface and diameter for example. Right?


OK...had another cup of coffee so the old noodle is synapsing away like a locomotive. I believe the font you are looking for is GDT.SHX. Take a look.


Best source to date! The gdt.shx works for me. Thanks ReMark!

Link to comment
Share on other sites

Oh really?

Go to google.com in anything but IE and type "do a barrel roll"


unfortunately i don't have that ability here at work, hopefully i can remember to take a look at it from home tonight :)

Link to comment
Share on other sites

  • 4 months later...
Correct me if I am wrong but when one uses the word "mechanical" they are referring to HVAC right?


I am a mechanical Design Draftsman, working in a civil environment at the moment, everyone assumes i mean HVAC.

Then i have to point say heavy Industrial Mechanical


god civil shirts me, fudged dimensions, changing dimensions and not the model, drawing in meters not millimeters, dimensions in model space ...everything has a dodgy factor to it.

Link to comment
Share on other sites

In terms of Building and building services, mechanical means mechanical services, so mostly hvac .an mechanical engineer can do mechanical services, hydraulic services, fire protection and vertical transportation design.
